Nylon Syringe Filters

AXIVA – NYLON SYRINGE FILTERS – STERILE

  • An integrated syringe filter unit having PP Housing and Nylon Membrane.
  • Excellent chemical compatibility with esters, bases and alcohols.
  • No pre-wetting required.
  • Excellent for filtration of particle – laden sample along with pre-filter (Less hand-pressure to filter difficult solution)

Key Features

  • Absolute microbial retention
  • High Flow rate
  • Low extractable
  • Low sample absorption
Media       –    Nylon66
Housing   –    Polypropylene

Technical Specification :

Retention Efficiency : 0.2 µm – LRV > 7 for Brevundimonas diminuta
0.45 µm – LRV > 7 for Serratia marcescens
Wettability : Hydrophilic
Effective filtration area : 0.1cm2 for 4mm, 0.8 cm2 for 13mm & 3.9 cm2 for 25mm &
4.6 cm2 for 33mm
Hold up volume : <10 µl for 4 mm, < 20 µl for 13 mm & < 50 µl for 25mm &
80µl for 33mm (after air purge)
Intergrity Test : Water bubble point > 50psi for 0.2 µm & >30 psi for 0.45 µm
Extractable (NVR) : Very low (with in limit as specified in USP XXIV)
Initial Water flow rate
(at 10 psi for 25 mm)
: 35.4 ml/min for 0.2 µm & 67.2 ml/min for 0.45 µm
Filtration Volume : < 1ml for 4mm, 1-10ml for 13mm & 10-100ml for 25mm &
30-150ml for 33mm

Sterilie :
Sterilization : ETO

APPLICATIONS :
  • HPLC Solvents Sample Filtration
  • Mobile phase separation
  • For aqueous as well as organic solvent filtration

ORDERING INFORMATION :

Cat NoSize/Dia (mm)Micron RatingNos./Pkt.
SFNY04R 40.2 µm100
SFNY04X40.45 µm100
SFNY13R130.2 µm100
SFNY13X130.45 µm100
SFNY25R250.2 µm50
SFNY25X250.45 µm50
SFNY33R330.2 µm50
SFNY33X330.45 µm50
nylon-syringe-filters

AXIVA – NYLON SYRINGE FILTERS – NON STERILE

Packed in transparent Plastic Jar (BULK PACK)

Application

  • HPLC & sample Preparations.
  • Ideal for aqueous or mixed organic samples.
  • Mobile Phase Separation
  • General biological sample filtration and clarification
  • Not recommended for strong acids and halogenated solvents.

ORDERING INFORMATION :


Cat No
Size/Dia (mm)Micron RatingNos./Pkt.
SFNY04RB40.2 µm100
SFNY04XB40.45 µm100
SFNY13RB130.2 µm100
SFNY13XB130.45 µm100
SFNY25RB250.2 µm100
SFNY25XB250.45 µm100
SFNY33RB330.2 µm50
SFNY33XB330.45 µm50
nylon-syringe-filters1
